選型參考表Selection reference table
|
機(jī) 型 Model |
拉 簧 Tension Spring |
參考線徑(mm) Wire Diameter |
張力范圍(g.f) Tension Scope |
張力桿 Tension Arm |
標(biāo)準(zhǔn)配置 Standard Set |
||
| SET-100 | S2 | Φ0.03-Φ0.06 | 10-25 | SA2 |
張力桿 SA2/SA3 拉簧 S2/S3/S4 |
||
| S3 | Φ0.05-Φ0.09 | 22-65 | SA3 | ||||
| S4 | Φ0.08-Φ0.14 | 60-100 | SA3 | ||||
| SET-200 | S2 | Φ0.03-Φ0.06 | 10-25 | SA2 |
張力桿 SA2/SA3 拉簧 S2/S3/S4/S5 |
||
| S3 | Φ0.05-Φ0.09 | 22-65 | SA3 | ||||
| S4 | Φ0.08-Φ0.14 | 60-150 | SA3 | ||||
| S5 | Φ0.14-Φ0.18 | 140-200 | SA3 | ||||
| SET-300 | S2 | Φ0.03-Φ0.06 | 10-25 | SA2/SA3 |
張力桿 SA2/SA3 拉簧 S2/S3/S4 |
||
| S3 | Φ0.05-Φ0.09 | 22-65 | SA3 | ||||
| S4 | Φ0.08-Φ0.14 | 60-150 | SA4 | ||||
| S5 | Φ0.14-Φ0.22 | 140-300 | SA4 | ||||
| SET-600 | S3 | Φ0.05-Φ0.09 | 22-65 | SA4 |
張力桿 SA4/SA5-2 拉簧 S2/S3/S5/S6 |
||
| S4 | Φ0.08-Φ0.14 | 60-150 | SA4 | ||||
| S5 | Φ0.14-Φ0.22 | 140-200 | SA4-2 | ||||
| S6 | Φ0.22-Φ0.35 | 350-600 | SA2-2 | ||||
| SET-1000 | SS3 | Φ0.10-Φ0.18 | 30-400 | SA4 |
張力桿 SA4/SA5 拉簧 SS3/SS4/SS5/SS6/SS7/SS8 |
||
| SS4/SS5 | Φ0.18-Φ0.35 | 200-700 | SA4 | ||||
| SS6/SS7 | Φ0.25-Φ0.45 | 400-1000 | SA5 | ||||
| SS8 | Φ0.43-Φ0.57 | 95-1880 | SA5 | ||||
